Description
YONG HENG 220V 300BAR AUTO STOP COMPRESSOR
With the Yong Heng 220V 300BAR Auto Stop Compressor, you can fill both your PCP rifle and HPA cylinder yourself. Holding safety and durability in mind, the Yong Heng comes packed full of features and is easy to operate. This high pressure, water-cooled (water pump included) auto stop version features a warning light, an automatic stop at 300BAR and fills up to 50L per minute.
These electrical compressors boast many features that ensure the safety of the operator and the longevity of the units. A power on/off switch and digital temperature gauge, as well as a warning light, are conveniently placed right on top near the carry handle. The nearby pressure gauge is marked in both psi and BAR with yellow, green and red colouring for extra visibility.
It makes use of an explosion-proof safety valve (burst disc), overload protection and a pressure release or bleed-off screw. Yong Heng supplied a cyclone separator to prevent and reduce oil and moisture inside the high pressure vessel that is filled. The high pressure hose features a 8mm quick-connect fitting for fast and easy coupling.
You also get a detailed operation manual illustrating setup and usage instructions, along with necessary spares to service or repair your Yong Heng when the time comes.
Test Inflating Results supplied by Manufacturer
It takes about 3 minutes 50 seconds to fill a 0.45L tank to 30MPA.
It takes about 8 minutes to fill a 1L tank to 300BAR.
STKO did an awesome review on a Yong Heng, showing how it works and demonstrating an actual air rifle fill.
SPECIFICATIONS
Model: Yong Heng Auto Stop
Shut Down: Auto Stop at 300BAR
Air Filtration: Two Water-Oil Separators
Voltage: 220V / 50HZ
Power Rating: 1.8KW
Inflating Speed: 2800R/Min
Noise: MAX 85DB
Air Flow Rate: 50L/Min
Working Pressure: 0-300BAR / 0-30MPA / 0-4500PSI
Cooling System: Water Cooled
Compression Stage: Two Stage
Lubrication Mode: Splash System
Material of Cover: Cast Aluminum
Material of Motor: 100% Pure Copper
Oil: Synthetic Reciprocation Compressor Oil or 5W40 Synthetic Motor Oil
Length: 360mm
Width: 180mm
Height: 370mm
Net Weight: 16.5kg
* Please Note: Compressors are shipped with no oil in the system, because of importation restrictions on oil in machinery. Images for illustrative purposes only. Variations may occur due to batch imported. Please ensure you read the Operation Manual before assembly and start-up. Due to the nature of the product and manufacturers not being able to control the use of the product, these items are not covered by warranty. * Temperature control is very important*
Supplied With:
Submersible Water Pump
Water Hose
High Pressure Air Fill Hose with Filter
Spare Filter Seals and Inserts
Breather Nozzle
2 x Pressure Relief Screws
Spare Explosion-Proof Safety Discs
Spare O-Rings
About Yong Heng
Nantong Yong Yi Heng Pneumatic Co., LTD, of Jiangsu, China started in 2015 as the manufacturer of authentic Yong Heng compressors.
Specialised in producing high pressure air pumps, which can be widely used for PCP systems, diving equipment and also other machinery. Exporting all over the world, including the US, EU, Australia and South Africa.
They have a huge line-up of products with various models available to suit every shooter’s needs. From hand pumps to compressors and everything in between.
They provide both 220V and 110V plugs to meet different markets.
