SEKHMET 28PRO GEN2 DIGITAL PRESSURE GAUGE 300BAR 1/8 BSPP

Description

SEKHMET 28PRO GEN2 DIGITAL PRESSURE GAUGE 300BAR 1/8 BSPP

The new Sekhmet 28Pro Gen2 Digital Pressure Gauge 300BAR 1/8 BSPP delivers highly accurate pressure readings. It measures air pressure from 15 to 300 BAR (218 to 4350 psi), while maintaining a maximum deviation of only 0.25%, ensuring consistent and reliable results.

Sekhmet has, of course, introduced several impressive upgrades to the 28 mm Pro Gen II model. For instance, the rechargeable battery now lasts up to 145% longer, offering extended performance between charges. In addition, the .49″ OLED display features buttons on the right, top, and left sides, making it simple and intuitive to operate.

Furthermore, the device carries an IPX7 waterproof rating, which means it can withstand submersion for up to 30 minutes at a depth of 0.5 metres without damage. Finally, the Sekhmet Pro Gen II 1/8 BSP Black 28 mm Digital Pressure Gauge can also be used in combination with a carbon cover for added durability and style.

Choose between three energy saving modes

The Sekhmet Digital mini pressure gauge pro gen 2 28mm 300bar offers three versatile display options to suit every preference. For instance, Auto Sleep Mode powers down the gauge automatically after a set period of inactivity, helping conserve energy, yet it instantly wakes up with a quick touch whenever needed. Similarly, Wake-on-Touch Mode keeps the gauge active in the background but lights up the display only after a shot or a simple tap, providing both convenience and efficiency. Finally, for users who prefer constant visibility, the display can remain always on, allowing continuous real-time monitoring without interruptions.

Settings

The Sekhmet Digital mini pressure gauge pro gen 2 28mm 300baroffers a variety of smart settings that allow you to fully customize your experience. For example, Simple Mode provides a clean and focused interface by displaying only the air pressure and removing all extra parameters, which makes reading fast and effortless. Similarly, Fill/Fire Wake-Up ensures the display activates automatically after a shot or a fill, so you only see updates when they matter most, improving efficiency during use.
In addition, Screen Off Time and Sleep Time give you control over the gauge’s power management. Screen Off Time lets you decide how long the display remains illuminated before turning off, allowing you to balance visibility and battery life with intervals ranging from 0 to 10 seconds. Sleep Time enhances energy conservation further by putting the gauge into sleep mode after a period of inactivity, from 0 to 60 minutes, so you can rely on longer battery performance without constantly worrying about power.
Finally, P-Minimum, Data Clear, and Rotate Screen add additional convenience and flexibility. P-Minimum allows you to define the minimum air pressure for your pressurised air reservoir, helping you safely monitor operating limits. Data Clear resets all stored information, including total shots, shots taken, last pressure used, and average pressure usage, so you can start fresh whenever needed. Meanwhile, Rotate Screen lets you adjust the display by 180°, enabling flexible installation and ensuring a clear view from any angle. Together, these features make the gauge highly versatile and user-friendly for every situation.

Key Display Features

Present amount of air pressure
Number of shots taken
Number of shots remaining
Amount of air pressure used with last shot
Average amount of air pressure used per shot
Temperature

SPECIFICATIONS

Accuracy: ±0.25%FS over + 10 to +40 deg C (+50 to + 104 deg F) ±0.5%FS over -10 to +8 0 deg C (+14to +149 deg F) Sizes: 1.1″(28mm)
Repeatability: Better than 0.5%
Range: 30 – 250 bar (435- 3625 psi
Process Connection Location: Back
Process Connection Size: 1/8 BSP Male
Dial: White figures on black background
Display: 0.49″ OLEO
Sampling Rate: 10Hz
Approvals High Pressure Gas

Package Includes

Gen-2 28Pro Gauge with 1/8 BSPP threaded connection
User Manual
Magnetic USB Charging Cable
Sealing Kit

Sekhmet Digital Mini Pressure Gauge Pro Gen 2 – Online Manual

*  Images are for illustrative purposes only. Do not use the Dowty seal at the top, use only 1 O‑ring seal at the bottom. Do not overtighten the gauge. Degas your air rifle before installation. DO NOT use a wrench.
